Building entries

Basic variant with inner seal

for buildings with a basement

MSH PolySafe GV1

Add to wish listAdd to wish list
Basic variant with inner seal - for buildings with a basement
USP
  • Test valve (pre-assembled)
  • Reliable installation due to front panel with integrated spirit level
  • Visual installation reliability due to built-in inspection opening
Gastight and watertight building entry for gas, water, power and telecommunications services. Basic variant 1 with internal sealing of 30 mm sealing width for installation in wall sleeves or waterproof concrete. The relevant external sealing elements are available for different wall types and building damp-proofing types.
Basic variant with inner seal - for buildings with a basement

Facts

Advantages:

  • Seals all supply lines through one entry
  • Continuous duct connection up to the main supply lines at the edge of the property possible
  • Modular system provides the appropriate external sealing depending on load class, construction type and wall structure

Scope of delivery:

  • 1 piece Front panel in internal sealing
  • 4 pieces sleeve pipes
  • 1 piece Test valve (pre-mounted)
  • 1 piece Movable spirit level (pre-assembled)
  • 8 pieces self-tapping screws M8x45 for sealing service lines

Dimensions:

  • Sealing width: 30 mm
  • Compatible with core drill/wall sleeve: ID: 199 - 203 mm
  • Maximum wall thickness: 500 mm (special lengths on request)

Properties:

  • DVGW-certified
  • To be supplemented with section sealing elements and one or more external sealing elements (depending on wall type and structure)
  • Can be optionally combined with connection elements and empty pipe system

Application range:

  • DIN 18533 W1-E, DIN 18533 W2.1-E
  • Waterproof concrete stress class 1, waterproof concrete stress class 2

Material:

  • Inner seal: Fibre-glass reinforced polyamide/EPDM
  • Sleeve pipes: PVC
  • Screws: stainless steel V2A (AISI 304L)

Tightness:

  • gastight and watertight to 1.0 bar
  • radon tight

Tests/Standards:

  • DVGW VP 601
Downloads

Installation instructions

Test reports

Data sheet & tender specification

For download of data sheet and tender specification please configurate the product in the section below and download via the symbol Download symbol

Variants

Article code Article number GTIN
MSH PolySafe GV1 1560000000 4052487162678
