Fibre cement wall sleeve

split

FZRG

Add to wish list

Consisting of two half-forms for retrofit sealing of already installed cables or pipes. For setting in concrete or mortar. Outer grooves all round ensure a tight and force-fit bond with the wall.

Facts

Advantages:

Split design for retrofit installation in break-throughs to seal already installed cables or pipes.
Suitable for all types of wall
Ideal connection to the concrete
Asbestos-free

Application range:

Waterproof concrete stress class 1 and 2

Downloads

Installation instructions

FZRG (PDF, 851KB)

Data sheet & tender specification

For download of data sheet and tender specification please configurate the product in the section below and download via the symbol Download symbol

Variants

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
80	≤ 140	200	FZRG80/200	1802080200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	240	FZRG80/240	1802080240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	250	FZRG80/250	1802080250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	300	FZRG80/300	1802080300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	365	FZRG80/365	1802080365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	400	FZRG80/400	1802080400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	500	FZRG80/500	1802080500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	600	FZRG80/600	1802080600	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	1000	FZRG80/1000	1802081000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
80	≤ 140	1200	FZRG80/1200	1802081200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
100	≤ 160	200	FZRG100/200	1802100200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	240	FZRG100/240	1802100240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	250	FZRG100/250	1802100250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	300	FZRG100/300	1802100300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	365	FZRG100/365	1802100365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	400	FZRG100/400	1802100400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	500	FZRG100/500	1802100500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	600	FZRG100/600	1802100600	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	700	FZRG100/700	1802100700	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	800	FZRG100/800	1802100800	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	1000	FZRG100/1000	1802101000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
100	≤ 160	1200	FZRG100/1200	1802101200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
125	≤ 170	200	FZRG125/200	1802125200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	240	FZRG125/240	1802125240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	250	FZRG125/250	1802125250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	300	FZRG125/300	1802125300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	365	FZRG125/365	1802125365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	400	FZRG125/400	1802125400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	500	FZRG125/500	1802125500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	600	FZRG125/600	1802125600	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	700	FZRG125/700	1802125700	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	800	FZRG125/800	1802125800	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	1000	FZRG125/1000	1802121000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
125	≤ 170	1200	FZRG125/1200	1802121200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
150	≤ 195	150	FZRG150/150	1802150150	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	200	FZRG150/200	1802150200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	240	FZRG150/240	1802150240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	250	FZRG150/250	1802150250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	300	FZRG150/300	1802150300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	365	FZRG150/365	1802150365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	400	FZRG150/400	1802150400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	450	FZRG150/450	1802150450	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	500	FZRG150/500	1802150500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	600	FZRG150/600	1802150600	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	700	FZRG150/700	1802150700	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	800	FZRG150/800	1802150800	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	1000	FZRG150/1000	1802151000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
150	≤ 195	1200	FZRG150/1200	1802151200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
200	≤ 255	150	FZRG200/150	1802200150	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	200	FZRG200/200	1802200200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	240	FZRG200/240	1802200240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	250	FZRG200/250	1802200250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	300	FZRG200/300	1802200300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	365	FZRG200/365	1802200365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	400	FZRG200/400	1802200400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	500	FZRG200/500	1802200500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	600	FZRG200/600	1802200600	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	700	FZRG200/700	3030357908	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	800	FZRG200/800	1802200800	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	1000	FZRG200/1000	1802201000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
200	≤ 255	1200	FZRG200/1200	1802201200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
250	≤ 305	200	FZRG250/200	1802250200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	240	FZRG250/240	1802250240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	250	FZRG250/250	1802250250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	300	FZRG250/300	1802250300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	365	FZRG250/365	1802250365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	400	FZRG250/400	1802250400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	500	FZRG250/500	1802250500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	700	FZRG250/700	3030358105	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
250	≤ 305	1000	FZRG250/1000	1802251000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
300	≤ 355	200	FZRG300/200	1802300200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	240	FZRG300/240	1802300240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	250	FZRG300/250	1802300250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	300	FZRG300/300	1802300300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	365	FZRG300/365	1802300365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	400	FZRG300/400	1802300400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	500	FZRG300/500	1802300500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	700	FZRG300/700	3030357909	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	1000	FZRG300/1000	1802301000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
300	≤ 355	1200	FZRG300/1200	1802301200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
350	≤ 405	200	FZRG350/200	1802350200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	240	FZRG350/240	1802350240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	250	FZRG350/250	1802350250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	300	FZRG350/300	1802350300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	365	FZRG350/365	1802350365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	400	FZRG350/400	1802350400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	500	FZRG350/500	1802350500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	1000	FZRG350/1000	1802351000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
350	≤ 405	1200	FZRG350/1200	1802351200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
400	≤ 470	200	FZRG400/200	1802400200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
400	≤ 470	250	FZRG400/250	1802400250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
400	≤ 470	300	FZRG400/300	1802400300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
400	≤ 470	350	FZRG400/350	3030332185	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
400	≤ 470	500	FZRG400/500	1802400500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
400	≤ 470	1000	FZRG400/1000	1802401000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
400	≤ 470	1200	FZRG400/1200	1802401200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
450	≤ 520	200	FZRG450/200	1802450200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	240	FZRG450/240	1802450240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	250	FZRG450/250	1802450250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	300	FZRG450/300	1802450300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	365	FZRG450/365	1802450365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	400	FZRG450/400	1802450400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	450	FZRG450/450	3030346206	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	500	FZRG450/500	1802450500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	750	FZRG450/750	3030348045	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	1000	FZRG450/1000	1802451000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
450	≤ 520	1200	FZRG450/1200	1802451200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
500	≤ 575	200	FZRG500/200	1802500200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	240	FZRG500/240	1802500240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	250	FZRG500/250	1802500250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	300	FZRG500/300	1802500300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	350	FZRG500/350	1802500350	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	365	FZRG500/365	1802500365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	400	FZRG500/400	1802500400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	500	FZRG500/500	1802500500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	800	FZRG500/800	3030336737	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	1000	FZRG500/1000	1802501000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
500	≤ 575	1200	FZRG500/1200	1802501200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
600	≤ 680	200	FZRG600/200	1802600200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	240	FZRG600/240	1802600240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	250	FZRG600/250	1802600250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	300	FZRG600/300	1802600300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	350	FZRG600/350	1802600350	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	400	FZRG600/400	1802600400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	500	FZRG600/500	1802600500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	600	FZRG600/600	1802600600	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	700	FZRG600/700	1802600700	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	800	FZRG600/800	1802600800	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	1000	FZRG600/1000	1802601000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
600	≤ 680	1200	FZRG600/1200	1802601200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
700	≤ 800	240	FZRG700/240	1802700240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	250	FZRG700/250	1802700250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	300	FZRG700/300	1802700300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	350	FZRG700/350	3030332186	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	365	FZRG700/365	1802700365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	400	FZRG700/400	1802700400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	500	FZRG700/500	1802700500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	1000	FZRG700/1000	1802701000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
700	≤ 800	1200	FZRG700/1200	1802701200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:

Wall sleeve ID (mm)	Wall sleeve OD (mm)	wall thickness (mm)	Article code	Article number
800	≤ 910	200	FZRG800/200	1802800200	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	240	FZRG800/240	1802800240	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	250	FZRG800/250	1802800250	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	300	FZRG800/300	1802800300	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	350	FZRG800/350	3030332189	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	365	FZRG800/365	1802800365	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	400	FZRG800/400	1802800400	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	500	FZRG800/500	1802800500	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
800	≤ 910	1000	FZRG800/1000	1802801000	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity:
